T-N16 - 16 bands 130-2600 MHz desktop signal Jamming device 42W

The T-N16 is a robust 16-frequency 4g cell jammer, specifically designed to block all 5 GPS bands (L1 to L5), offering reliable protection against satellite tracking. With a total output power of 42 watts, it covers a range of up to 50 meters, and each of its 16 antennas can be adjusted from zero to full power. The device can be powered either by a 220V power supply or a car battery using the included cable with terminals.

Equipped with an efficient cooling system, the T-N16 operates continuously in 24/7 mode. It effectively blocks the 130-2600 MHz frequency range, preventing digital transmissions. The jammer is ideal for environments where signal disruption is necessary, such as theaters, hospitals, churches, and schools—particularly during exams. The device’s flexibility allows it to be configured to meet the needs of various locations, ensuring comprehensive signal suppression wherever needed. You can carefully review all available frequencies:

CDMA 850-895MHz 3W
2G DCS PCS 1800-1990MHz 3W
3G UMTS WCDMA 2100-2170MHz 3W
4G LTE 700-800MHz 2W
4G WiMAX 2500-2700MHz 3W
WIFI 11b/g/n 2400-2500 MHz 2W
RC 433MHz 3W
RC 315MHz 3W
RC 868Mhz 3W
GPS L1 1575Mhz 2W
GPS L2 1227Mhz 2W
GPS L5 1176.45MHz
VHF:130-180MHz
UHF:400-480MHz
Lojack 173MHz 3W
4G LTE 1700-1800MHz

The effective range of the jammer can vary based on the proximity to cellular towers and local conditions. The specified radius corresponds to a signal suppression level of 60-80%. For optimal performance, position the device at least 200 meters away from any nearby cellular towers.

Suppressor specifications:

Total output power: 42 W
Power supply: 12V, 16.5A
Transmission radius: from 50 to 200 meters
Cooling system: 4 fans
Operating temperature: from -10 to +45°C
Packaging size: 465x420x12 mm
Packaging weight: 6.3 kg
Dimensions without antenna: 400x235x60 mm
Antenna length: 380 mm
Weight: 6.1 kg
